General:
StatusActive
CategoryCrimp Housings
Series6471
ApplicationSignal, Wire-to-Board
OverviewKK® Interconnect System - Molex
Product NameKK® 254
UPC800753594098
Physical:
Circuits (maximum)3
Color - ResinNatural (White)
Flammability94V-0
GenderFemale
Glow-Wire CompliantNo
Lock to Mating PartYes
Material - ResinNylon
Net Weight0.320/g
Number of Rows1
Packaging TypeBag
Panel MountNo
Pitch - Mating Interface2.54mm
Pitch - Termination Interface2.54mm
Polarized to Mating PartYes
StackableNo
Temperature Range - OperatingSee Product Specification
Agency Certification:
Please find UL Certificates by searching the UL Database using the Molex Series Number. Click here to visit the UL Database
CSALR19880
ULE29179
Solder Process Data:
Lead-freeProcess CapabilityWAVE
Material Info:
Old Part Number6471-03(I)
6710 BL013
6710 BL005
6710 BL001
6710 BK005
